| Performance | |
| Steam output | 192 kg/h. |
| Heat output | 127.543 kcal |
| Operating pressure | 1-10 bar |
| Max. operating pressure | 11.5 bar |
| Max. steam temperature | 184,0 °C |
| Number of heating elements | 2x 7x 9kW |
| Electrical dimensions | |
| Operating voltage | 400 Volt |
| 50 Hz | |
| 3+PE phases | |
| Heating power | 2x 63 kW |
| Total connected load | 2x 64 kW |
| Rated current | 2x 92 A |
| Protection on site | 2x 100 A |
| Min. cross section | 2x 4x35 mm² |
| Connector plug | 2x CEE 125A |
| Installation dimensions | |
| Steam pipe | DN25 |
| Water intake | ET R½" |
| Blowdown valve | DN20 |
| Safety valve | DN25 |
| Overflow / Tank drainage | AG G¾" |
| Condensate inlet tank | IT G¾" |
| Flash steam | IG G1½" |
| Emissions | |
| Noise | 63 db |
| Dimensions | |
| Height | 1.860 mm |
| Width | 1.600 mm |
| Depth | 1.450 mm |
