Performance | |
| Steam output | 384 kg/h. |
| Heat output | 255 kcal |
| Operating pressure | 1-10 bar |
| Max. operating pressure | 11.5 bar |
| Max. steam temperature | 184,0 °C |
| Number of heating elements | 4x 8x 9kW |
Electrical dimensions | |
| Operating voltage | 400 Volt |
| 50 Hz | |
| 3+PE phases | |
| Heating power | 4x 72 kW |
| Total connected load | 4x 73 kW |
| Rated current | 4x 106 A |
| Protection on site | 4x 125 A |
| Min. cross section | 4x 4x 50 mm² |
| Connector plug | 4x CEE 125A |
Installation dimensions | |
| Steam pipe | DN32 |
| Water intake | 2x ET R½“ |
| Blowdown valve | DN32 |
| Safety valve | DN32 |
| Overflow / Tank drainage | 2x AG G¾“ |
| Condensate inlet tank | 2x IT G¾" |
| Flash steam | 2x IG G1½" |
Emissions | |
| Noise | 63 db |
Dimensions | |
| Height | 1.860 mm |
| Width | 3.200 mm |
| Depth | 1.450 mm |
